EN 14605

Protective clothing for protection against liquid chemicals.

What is EN 14605 standard?

This standard specifies performance requirements for clothing with liquid-tight (type 3) or spray-tight (type 4) seams and includes requirements for apparel that provides protection for specific parts of the body only (types PB [3] and PB [4]).

EN 14605:2005 - PROTECTIVE CLOTHING AGAINST LIQUID CHEMICALS - TYPE 3 OR 4

(EN 14605:2005 supersedes EN 467:1995, EN 465:1995, EN 466-1:1995.)

EN 14605 explained

Types 3 and 4: Differences and Applications – Implications of Permeation Testing (EN 374-3 or ISO 6529)

The key difference between types 3 and 4 relates to the pressure and volume of a liquid spray:

•Type 3 is a strong jet of liquid such as that from a pressure sprayer
•Type 4 is a lighter spray such as that from a sprinkler system (i.e., substantial volume but lower in pressure)

In EN 14605 certification testing, this difference is reflected primarily in the finished garment spray test and not by any comparative mechanical property or by chemical permeation or barrier assessment tests.

Both types 3 and 4 must have sealed seams. EN 14605 requires at least one chemical permeation test on a seam (as well as the fabric) with a minimum score in class 1 (i.e., >10 minutes). No type of stitched seam will achieve this result against any chemical.

Type 3 and 4 certification also requires a permeation test on the fabric against at least one chemical with a minimum score in class 1 (i.e., >10 minutes). This standard does not specify that any particular chemical must be used for this test so, theoretically, a garment could be certified to type 3 or 4 with a permeation test against, for example, water while showing a normalised breakthrough of 11 minutes. However, a fabric with such a poor barrier against water would be unlikely to pass the finished garment spray tests.

Certification to types 3 and 4 do not indicate general suitability for protection against any specific chemical or a general chemical protective application. An assessment of the permeation barrier against specific chemicals should be made as part of every risk assessment.

Permeation classification:
• Class 1 > 10 min
• Class 2 > 30 min
• Class 3 > 60 min
• Class 4 > 120 min
• Class 5 > 240 min
• Class 6 > 480 min
